Sony FX5 Full-Frame Cinema Camera

Designed for filmmakers and content creators who demand uncompromising image quality in a compact form factor, the Sony FX5 Cinema Camera brings next-generation Cinema Line performance to productions of every scale. Powered by a newly developed 16.6MP full-frame stacked Exmor RS CMOS sensor, the advanced BIONZ XR2 image processor, and a dedicated AI Processing Unit, the FX5 delivers high-speed performance, remarkable low-light sensitivity, and professional cinema workflows for feature films, documentaries, commercials, and broadcast.

With support for internal 16-bit X-OCN RAW recording, 5K Open Gate capture, 15+ stops of dynamic range, and high-frame-rate recording up to 5K 120p and 4K 240p, the FX5 provides ultimate flexibility from acquisition to post-production.

Detailed Product Breakdown

1. Advanced Imaging & AI Autofocus

At the core of the FX5 is Sony's newly developed full-frame sensor and BIONZ XR2 processing engine. Coupled with 759 phase-detection Fast Hybrid AF points and deep-learning AI recognition, the FX5 keeps fast-moving subjects pin-sharp even at wide apertures and low light levels.

2. Flexible Post-Production Workflows

The introduction of internal 16-bit X-OCN compressed RAW recording gives cinematographers over 280 trillion colors to work with in post-production while saving storage space. 5K Open Gate capture gives editors freedom to crop for vertical social media, 16:9 widescreen, or 2.39:1 anamorphic formats without loss of resolution.

3. Built for Rigorous On-Set Production

The compact body inherits the modular Cinema Line design:

• 4-Axis Multi-Angle Touch LCD: Bright 3.5-inch monitor optimized for high and low angle rigging.

• Comprehensive Connectivity: Dual USB-C ports, Full-Size HDMI Type-A, 2.5G Ethernet, and Timecode BNC adapter support.

• Dual Card Slots: Dual CFexpress Type A / SD UHS-II slots support continuous high-bitrate recording.

• Pro Audio Ready: Fully compatible with the optional XLR Top Handle Unit with support for 96kHz / 32-bit float 4-channel audio.

Core Specifications

• Sensor: 16.6MP Full-Frame Back-Illuminated Stacked Exmor RS CMOS

• Image Processor: BIONZ XR2 with integrated AI Processing Unit

• Dynamic Range: 15+ Stops (S-Log3)

• Base ISO: Triple Base ISO (800 / 4000 / 12800)

• Internal RAW: 16-bit Scene-Linear X-OCN (LT / C1 / C2)

• Max Video Resolution: 5K Open Gate (up to 120fps), 4K (up to 240fps)

• Autofocus Points: 759 Phase-Detection Points with AI Subject Recognition

• Stabilization: 5-Axis In-Body Sensor-Shift + Dynamic Active Mode

• Media Slots: Dual CFexpress Type A / SDXC UHS-II

• Weight: Approx. 750g (Body Only)
